TINGEN 1200W Grid Tie Inverter With LCD Solar Panel Input 55V-90V Battery Voltage Input 48V AC Output 90V-140V

Specifications Output Power:1400W/110V DC Input: 20V-50V AC Output Voltage: 90V-140V Frequency Range: 48Hz ~ 62Hz Auto Solar Panel Voltage: Vmp30-39V; Voc38-46V Solar Panel Power: minimum 300W, maximum 1700W Certification:CE RoHS Package include: 1XGrid Tie Inverter 1 x Power Cord(us) 1 x English User's Manaul During electricity generation with PV panels, there are no harmful greenhouse gas emissions Start DIY your solar system. Reduce your electricity bill. 1400W Grid tie inverter , Pure Sine Wave Inverter DC20V-50V to AC90-140V Output. 36V Solar Panels,Vmp is 35-39V and Voc is 42-46V If the generated power exceeds your usage, the extra power is sent back to your local grid system, and you are eligible for credit from your power provider company. Please be noted, This grid tie inverter cannot be used as off grid/stand alone solar system. Can not supply power directly to the AC loads. DO NOT use solar controller load ports to connect to the inverter It will perfect compatible with solar panels at 30V or 36V (Vmp) It cannot be used with 12V/24V/48V battery. Only use the 36V battery to power the inverter How to DIY Grid Tie Inverter Solar System? DC20-50V version. DC Input Easy to install, DC connect your solar panel (red terminals connect +, black terminals connect -) Note 1: Do not connect the positive and negative poles. Note 2: Please tighten the DC end of the inverter. AC output The AC cord to the inverter 3 foot outlet, then the AC cord to home 3 pin AC outlet. The switch of the home outlet must be turned on. Note 1: The local power grid must be normal. In order to achieve higher power use requirements, the use of this product can be stacked, such as: 4 grid tie inverter 1400W of stack used is equal to 5600W, and the number of open stacks (No Quantitative Restrictions). MPPT technology Creative MPPT tech makes efficiency higher than 99%. Peak conversion 80%. Multiple protections Islanding; Short-circuit; converse connection; Low Voltage; Over Voltage; Over temperature Protection Fan Cooling Intelligence Fan-on temperature 45℃ and off < 40℃. High-speed ventilation fans to help keep the inverter running at a low temperature. If the DC connection is loose and causes a short circuit, then smoke may be emitted. The inverter adopts aluminum alloy casing, so there is no fire. Stackable Grid Tie Inverter - Parallel modular components design (Stackable use) is convenient for systems setting, flexible combination and system scalability. Grid Tie Inversor - MPPT Function/Over Current Protection/Over Temperature Protection/Reverse Polarity Protection/Island Protection/Stackable【Y&H provides 30 days free return and 1 year warranty. If you encounter product problems, please contact the seller's support.】 This is because the excess power from the inverter will be fed back into the grid, resulting in increased electricity costs.
